48V Diamondback Motorized Dolly with Winch for Inflatables

IN STOCK – CALL (888) 901-9283 OR CLICK “REQUEST QUOTE” BUTTON TO ORDER

(Available for immediate shipment. Not available for online checkout.)

48V Diamondback Motorized Dolly with Winch for Inflatables – One-Person Power Redefined

Product Description

Take inflatable transport to the next level with the 48V Diamondback Motorized Dolly with Winch for Inflatables — the most advanced, operator-built dolly in the rental industry. Engineered from the ground up by seasoned inflatable professionals, the Diamondback combines unmatched power, premium craftsmanship, and precision control to help you move heavy inflatables faster, safer, and easier than ever before.

The integrated 12V winch system transforms solo operation into a seamless process — allowing one person to roll, lift, or stand up even the largest commercial inflatables with total control. From setup to teardown, this unit eliminates strain, minimizes crew size, and maximizes productivity — a true game-changer for every serious rental operator.

Key Features & Benefits

• 48V Specialized Electric Transaxle – Custom-engineered with CNC-machined alloy gears for low noise, high torque, and long-term reliability.

• 48V Lithium-Ion Battery System (20A BMS) – Reliable runtime and safety protection with onboard charger and real-time voltage display.

• Integrated 2000 lb Rated Winch System – Includes wireless remote control and onboard E-stop switch for effortless rolling and lifting of heavy inflatables by a single operator.

• Winch-Dedicated 12V Lithium Battery – Includes onboard charger and voltage indicator to keep your winch powered and ready at all times.

• High-Torque Brushless Motor Drive – Two-stage gearing ensures exceptional pulling strength while maintaining quiet, efficient operation.

• 1500 lb Payload Capacity – Engineered for the heaviest commercial inflatables, tents, or event gear.

• Electromagnetic Brake System – Smart software integration provides smooth acceleration, deceleration, and automatic stopping on slopes.

• Precision Fabrication – CNC-cut, 100% MIG-welded industrial frame using 1/8" steel tubing and a 1/4" base plate for unbeatable strength.

• Stainless Steel Hardware & Powder-Coated Finish – Primed, sandblasted, and powder-coated in Desert Tan for superior rust and chip resistance.

• Terrain-Ready Design – Equipped with 18 × 8.5-8 drive tires and heavy-duty pneumatic casters that glide over grass, gravel, and uneven ground.

• Retractable Ratchet Strap System – Secure your load during movement with confidence.

• Quiet Axle Operation – Smooth, controlled, and whisper-quiet performance.

• Brake Disengagement Option – Easily switch to manual mode when power is off.

Specifications

Main Power System: 48V Lithium Battery with Onboard Charger & Voltage Indicator
Winch System: 2000 lb Rated Winch with Wireless Remote, 12V Lithium Battery, and Onboard Charger
Drive Motor / Transaxle: 48V Brushless Direct Drive with CNC-Machined Gears
Frame Material: 1/8" Steel Tubing / 1/4" Base Plate – 100% MIG-Welded
Hardware: 100% Stainless Steel
Finish: Primed & Powder-Coated Matte Desert Tan
Weight Capacity: 1500 lbs Max
Tires: (2) 18 × 8.5 × 8 Drive Tires – 815 lb load each
Casters: (2) 4.10 × 3.50-4 Pneumatic Swivel Casters – 36 PSI, 750 lb load each
Brake System: Electromagnetic with Manual Disengage
Dimensions: 35 ¾" W × 68" H
Warranty: 1 Year Limited Warranty – Parts & Support Included
Price: Starts at $5,795

Why the Winch Model Makes the Difference

The integrated winch model isn’t just an upgrade — it’s a force multiplier. Operators can now handle large commercial inflatables solo without relying on extra manpower. Whether you’re rolling up a 27ft water slide or positioning an obstacle course, the wireless-controlled 2000 lb winch gives you total command. No strain, no stress — just pure efficiency and control at your fingertips.

Built for Operators, Proven in the Field

The Diamondback Motorized Dolly has been field-tested in rental operations for over a year to ensure long-term dependability and power. Each dolly is handcrafted, sandblasted, and powder-coated by our certified team to guarantee a consistent, corrosion-resistant finish.

When you choose the Diamondback, you’re not just buying a machine — you’re investing in a tool designed by operators who know the challenges of your business firsthand.

For questions, support, or replacement parts, call (888) 901-9283 or email sales@bouncewave.com anytime.
